The project titled “Electromagnetic Coil-Based Gun” proposes an electromagnetic propulsion system designed to launch a projectile without using gunpowder. The system demonstrates the principle of electromagnetic force, in which magnetic fields generated by energized coils produce a force on a suitable ferromagnetic object. The proposed system consists of copper electromagnetic coils, electronic control circuitry, capacitors, a supporting frame, a pipe, and an Arduino UNO microcontroller. A three-stage coil arrangement is considered to demonstrate the sequential operation of electromagnetic coils. The coils are arranged along a common axis, and their operation is controlled electronically to illustrate how electromagnetic fields can influence the movement of a ferromagnetic object. The Arduino UNO serves as the main control unit and interfaces with the input button and electronic switching circuitry. When the user presses the button, the controller initiates the programmed sequence, demonstrating coordinated coil activation. Capacitors and electronic components support the operation of the electromagnetic circuit, while the frame provides mechanical support for the assembly. This project demonstrates the application of electromagnetism, microcontroller-based control, and electronic switching in projectile propulsion. It provides an educational platform for understanding electromagnetic principles and their applications in modern engineering. For safe implementation, the system should be designed as a low-energy laboratory demonstrator using a non-projectile load rather than a device intended to launch bullets at high speeds.

Objectives:

  To design and develop an electromagnetic coil-based propulsion system that demonstrates the principle of electromagnetic force.

  To study the working principle of electromagnetic coils and their ability to generate magnetic fields when energized.

  To implement an Arduino UNO microcontroller for controlling the sequential operation of multiple electromagnetic coils.

  To develop an electronic switching circuit for controlling coil activation and deactivation.

  To demonstrate the movement of a ferromagnetic object using electromagnetic force in a controlled laboratory setup.

  To understand the role of copper coils, capacitors, and electronic components in electromagnetic systems.

  To improve the understanding of microcontroller-based automation and electromagnetic applications.

  To ensure safe operation by using a low-energy demonstrator and appropriate electrical protection mechanisms.

Components used:

• Adapter.
• SMPS Power supply
• Arduino UNO.
• Relays.
• Copper coils.



Software’s used:

1. Arduino IDE Studio compiler for dumping code
2. Embedded C programming.
3. Express SCH for Circuit design.
